General Purpose Industrial Electric Motors of AIR Series (EPOS electric)

Electric motors "EPOS electric" can be used in various branches of industry and can meet the highest requirements.

TECHNICAL SPECIFICATION

For general purpose industrial motors, which are blown with squirrel-cage rotor and the axis of rotation height from 80 to 355 mm:

• Power – from 2 kW to 315 kW
• Climate version – У3 (moderate macroclimate, outdoor/indoor)
• Insulation class – F
• Standard protection class – IP55
• Location of terminal box – above
• Rated-network frequency – 50 Hz
• Nominal voltage – 220/380 V, 380/660 V
• Ambient temperature – not more than 40 °C

Standards

GOST R 51689-2000, GOST 183-74

Construction types

Main forms: ІМ1001, ІМ2001, ІМ3001

Basic dimensions
